| Part No |
90NX0AL1-M002K0 |
| Model Name |
P3606CCAP-MB0075 |
| EAN Code |
4711636640237 |
| UPC Code |
199291640238 |
| WEEE |
1.35 |
| BASE UNIT |
VSNX0AL1-BU1112 |
| |
|
| Operating System |
Non-preinstalled OS |
| LCD cover-material |
Plastic |
| LCD cover-color |
Misty Grey |
| Top case-material |
Plastic |
| Top case-color |
Misty Grey |
| Bottom case-material |
Plastic |
| Bottom case-color |
Misty Grey |
| Military grade |
US MIL STD 810H military grade standard (24 procedures) |
| Panel Size |
16.0-inch |
| Backlit |
LED Backlit |
| Brightness |
300nits |
| Resolution |
WUXGA (1920 x 1200) 16:10 |
| Glare |
Anti-glare display |
| Color gamut |
NTSC: 45% |
| View angle(H/V) |
160/160 |
| Response time(Typ/Max) (ms) |
20/25 |
| Refresh rate |
60Hz |
| Contrast (Typ) |
1000:1 |
| Touch Panel |
Non-touch screen |
| Screen-to-body ratio |
90 % |
| IPS-level |
Wide view |
| Processor |
Intel® Core™ Ultra 5 Processor 225H 1.7 GHz (18MB Cache, up to 4.9 GHz, 14 cores, 14 Threads); Intel® AI Boost NPU up to 13 TOPS |
| Neural processor |
Intel® AI Boost NPU |
| Chipset |
N/A |
| Discrete/Share |
Share |
| Integrated GPU |
Intel® Graphics |
| VRAM |
N/A |
| How to upgrade memory |
Upgradable; Need to remove bottom/top case |
| Expansion Slot(includes used) |
2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4 |
| DIMM Memory |
16GB DDR5 SO-DIMM |
| Total System Memory |
DDR5 16GB |
| Storage |
512GB M.2 2280 NVMe™ PCIe® 4.0 SSD |
| Front-facing camera |
1080p FHD camera with IR function to support Windows Hello
With privacy shutter |
| Wireless |
Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card |
| NumberPad |
N/A |
| FingerPrint |
FingerPrint |
| Keyboard type |
Backlit Chiclet Keyboard |
| Keyboard language |
Hungarian |
| I/O ports |
1x USB 3.2 Gen 2 Type-C support display / power delivery
2x USB 3.2 Gen 1 Type-A
1x Thunderbolt™ 4, compliant with USB4, support display / power delivery
1x HDMI 2.1
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet |
| Audio |
Audio by Dirac
Built-in speaker
Built-in array microphone |
| Battery |
70WHrs, 4S1P, 4-cell Li-ion |
| AC Adapter |
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord) |
| Required charging power |
Min: 55W
Max: 65W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher. |
| Dimension (WxHxD) |
35.93 x 25.35 x 1.17 ~ 1.99 cm (14.15" x 9.98" x 0.46" ~ 0.78") |
| Starting Weight (with Battery) |
1.87 kg (4.12 lbs) |
| Starting Weight (w/o Battery) |
1.61 kg (3.55 lbs) |
| Security |
Kensington Nano Security Slot™(6x 2.5mm)
Fingerprint sensor integrated with Power Key
IR webcam with Windows Hello support
Intel® Boot Guard
Microsoft Security Level 3
HDD User Password Protection and Security
BIOS Integrity Measurement Support
CSME BIOS Redundancy Assistance
Trusted Platform Module (Firmware TPM)
Enhanced Password Strength
BIOS setup user password
BIOS Booting User Password Protection
Intel CSME Firmware Resilience
Intel® BIOS Guard
Support Absolute Persistence 2.0 (Computrace)
BIOS Self Recovery
ASUS ExpertGurdian with NIST SP 800 155 compliance
N/A |
| MyASUS feature |
System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals |
| MyExpert Features |
Advanced Tool
ExpertMeet(All)
SafeGuard Backup(Dual SSD, additional purchase before shipment) |
| Built-in Apps |
MyASUS
ASUS MyExpert (Not supported in China, 16GB RAM or higher)
AI ExpertMeet (China only) |
| Disclaimer for Built-in Apps |
Built-in Apps vary from OS SKU.
*MyASUS/McAfee don't support in Clean Build/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) |
| Reparability Index (for Belgium) |
09.2 |
| Reparability Index (for France) |
09.7 |
| Ecolabels & Compliances |
Energy star 9.0
FSC Recycled
REACH
RoHS |
| Base Warranty |
3Y Pick up/ return |
| Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty |
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgrade
ACX13-007023NX//2Y Extension; 5Y OnSite Service(Next Business Day)*upgrade
ACX15-005821NX//2Y Extension; 5Y OnSite Service(Next Business Day); 5Y HDD Retention*upgrade
*If you would like to know the details, please contact your sales teams. |
| Battery warranty |
Commercial NB P series Battery warranty follow system warranty. |
| Sustainable Material_Top cover(A part) |
30% PCR recycled plastic(cover or inner frame)
30% PIR recycled aluminum |
| Sustainable Material_Keyboard frame (C part) |
30% PCR recycled plastic(cover or inner frame) |
| Sustainable Material_Bottom cover (D part) |
30% PCR recycled plastic(cover or inner frame) |
| Sustainable Material_Battery |
30% PCR recycled plastic |
| Sustainable Material_Keyboard |
50% PCR recycled plastic cap |
| Sustainable Material_Speaker |
45% PCR + 5% OBP PCR recycled plastic enclosure |
| Sustainable Material_Total PCR recycled plastic |
28.2% |
