| Part No |
90NX0861-M004E0 |
| Model Name |
P5405CSA-NZ0128X |
| EAN Code |
4711636548007 |
| UPC Code |
199291548008 |
| WEEE |
0.833 |
| BASE UNIT |
VSNX0861-BU1100 |
| |
|
| Operating System |
Windows 11 Pro |
| Office |
1-month trial for new Microsoft 365 customers. Credit card required. |
| LCD cover-material |
Aluminum |
| LCD cover-color |
Misty Grey |
| Top case-material |
Aluminum |
| Top case-color |
Misty Grey |
| Bottom case-material |
Aluminum |
| Bottom case-color |
Misty Grey |
| Military grade |
US MIL-STD 810H military-grade standard |
| Panel Size |
14.0-inch |
| Backlit |
LED Backlit |
| Brightness |
400nits |
| Resolution |
WQXGA (2560 x 1600) 16:10 |
| Glare |
Anti-glare display |
| Color gamut |
sRGB: 100% |
| View angle(H/V) |
178/178 |
| Response time(Typ/Max) (ms) |
25/30 |
| Refresh rate |
144Hz |
| Contrast (Typ) |
1200:1 |
| Touch Panel |
Non-touch screen |
| Screen-to-body ratio |
90 % |
| IPS-level |
Wide view |
| Processor |
Intel® Core™ Ultra 5 Processor 226V 16GB 2.1 GHz (8MB Cache, up to 4.5 GHz, 8 cores, 8 Threads); Intel® AI Boost NPU up to 40 TOPS |
| Neural processor |
Intel® AI Boost NPU |
| Chipset |
N/A |
| Discrete/Share |
Share |
| Integrated GPU |
Intel® Arc™ 130V GPU |
| VRAM |
N/A |
| How to upgrade memory |
Not Available |
| Expansion Slot(includes used) |
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4 |
| On board memory |
16GB LPDDR5X Memory on Package |
| Total System Memory |
LPDDR5X 16GB |
| Storage |
512GB M.2 2280 NVMe™ PCIe® 4.0 SSD |
| Front-facing camera |
1080p FHD camera with IR function to support Windows Hello
With privacy shutter |
| Wireless |
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card |
| NumberPad |
N/A |
| FingerPrint |
FingerPrint |
| Keyboard type |
Backlit Chiclet Keyboard |
| I/O ports |
2x USB 3.2 Gen 2 Type-A
2x Thunderbolt™ 4, compliant with USB4, support display / power delivery
1x HDMI 2.1
1x 3.5mm Combo Audio Jack |
| Audio |
Dolby Atmos
Smart Amp Technology
Built-in array microphone |
| Battery |
63WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter |
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord) |
| Required charging power |
Min: 55W
Max: 65W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher. |
| Dimension (WxHxD) |
31.20 x 22.32 x 1.49 ~ 1.64 cm (12.28" x 8.79" x 0.59" ~ 0.65") |
| Weight (with Battery) |
1.29 kg (2.84 lbs) |
| Weight (w/o Battery) |
1.06 kg (2.34 lbs) |
| Security |
Fingerprint sensor integrated with Power Key
IR webcam with Windows Hello support
Kensington Nano Security Slot™(6x 2.5mm)
BIOS Booting User Password Protection
BIOS Integrity Measurement Support
BIOS Self Recovery
CSME BIOS Redundancy Assistance
HDD User Password Protection and Security
Intel CSME Firmware Resilience
Intel® BIOS Guard
Intel® Boot Guard
Microsoft Pluton Security Processor
Microsoft Security Level 3
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
N/A |
| Antivirus |
McAfee® 30 days free trial |
| MyASUS feature |
System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS |
| MyExpert Features |
ExpertMeet(All)
SafeGuard Backup(Dual SSD, additional purchase before shipment) |
| Built-in Apps |
AI ExpertMeet (AI features need devices with 12GB RAM or more)
MyASUS |
| Disclaimer for Built-in Apps |
Built-in Apps vary from OS SKU.
*MyASUS/McAfee don't support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) |
| Reparability Index (for Belgium) |
95.2 |
| Reparability Index (for France) |
98.3 |
| Ecolabels & Compliances |
EPEAT Gold with Climate+
Energy star 8.0
FSC Recycled
REACH
RoHS
TCO Certified |
| Base Warranty |
3Y Pick up/ return |
| Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty |
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgrade
ACX13-007023NX//2Y Extension; 5Y OnSite Service(Next Business Day)*upgrade
ACX14-017300NX//3Y HDD Retention*upgrade
ACX15-011800NX//3Y OnSite Service(Next Business Day); 3Y Accidental Damage Protection*; 3Y HDD_Retention*upgrade
*If you would like to know the details, please contact your sales teams. |
| Battery warranty |
Commercial NB P series Battery warranty follow system warranty. |
| Sustainable Material_Top cover(A part) |
30% PCR recycled plastic(cover or inner frame)
30% PIR recycled aluminum |
| Sustainable Material_Keyboard frame (C part) |
30% PCR recycled plastic(cover or inner frame)
30% PIR recycled aluminum |
| Sustainable Material_Bottom cover (D part) |
30% PCR recycled plastic(cover or inner frame)
30% PIR recycled aluminum |
| Sustainable Material_Battery |
30% PCR recycled plastic |
| Sustainable Material_Keyboard |
50% PCR recycled plastic cap
50% PIR recycled aluminum bracket |
| Sustainable Material_Speaker |
45% PCR + 5% OBP PCR recycled plastic enclosure |
| Sustainable Material_Total PCR recycled plastic |
29%
|
