| Part No |
90NX09U2-M00800 |
| Model Name |
PM3406CHA-LY0216 |
| EAN Code |
4711636547987 |
| UPC Code |
199291547988 |
| WEEE |
1.02 |
| BASE UNIT |
VSNX09U2-BUA111 |
| |
|
| Operating System |
Non-preinstalled OS |
| LCD cover-material |
Aluminum |
| LCD cover-color |
Misty Grey |
| Top case-material |
Plastic |
| Top case-color |
Misty Grey |
| Bottom case-material |
Plastic |
| Bottom case-color |
Misty Grey |
| Military grade |
US MIL STD 810H military grade standard (24 procedures) |
| Panel Size |
14.0-inch |
| Backlit |
LED Backlit |
| Brightness |
300nits |
| Resolution |
WUXGA (1920 x 1200) 16:10 |
| Glare |
Anti-glare display |
| Color gamut |
NTSC: 45% |
| View angle(H/V) |
160/160 |
| Response time(Typ/Max) (ms) |
20/25 |
| Refresh rate |
60Hz |
| Contrast (Typ) |
800:1 |
| Touch Panel |
Non-touch screen |
| Screen-to-body ratio |
88 % |
| IPS-level |
Wide view |
| Processor |
AMD Ryzen™ 7 8840HS Processor 3.3GHz (16MB Cache, up to 5.1 GHz, 8 cores, 16 Threads); AMD Ryzen™ AI up to 39 TOPs |
| Neural processor |
AMD Ryzen™ AI up to 16 TOPs |
| Chipset |
N/A |
| Discrete/Share |
Share |
| Integrated GPU |
AMD Radeon™ 780M |
| VRAM |
N/A |
| How to upgrade memory |
Upgradable; Need to remove bottom/top case |
| Expansion Slot(includes used) |
2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4 |
| DIMM Memory |
16GB DDR5 SO-DIMM |
| Total System Memory |
DDR5 16GB |
| Storage |
512GB M.2 2280 NVMe™ PCIe® 4.0 SSD |
| Front-facing camera |
1080p FHD camera
With privacy shutter |
| Wireless |
Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card |
| NumberPad |
N/A |
| FingerPrint |
FingerPrint |
| Keyboard type |
Backlit Chiclet Keyboard |
| I/O ports |
1x USB 3.2 Gen 2 Type-C support display / power delivery
1x USB 4.0 Type-C support display / power deliver
2x USB 3.2 Gen 1 Type-A
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet |
| Audio |
Audio by Dirac
Built-in speaker
Built-in array microphone |
| Battery |
70WHrs, 4S1P, 4-cell Li-ion |
| AC Adapter |
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord) |
| Required charging power |
Min: 55W
Max: 65W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher. |
| Dimension (WxHxD) |
31.60 x 22.78 x 1.07 ~ 1.89 cm (12.44" x 8.97" x 0.42" ~ 0.74") |
| Weight (with Battery) |
1.54 kg (3.40 lbs) |
| Weight (w/o Battery) |
1.28 kg (2.82 lbs) |
| Security |
Fingerprint sensor integrated with Power Key
Kensington Nano Security Slot™(6x 2.5mm)
BIOS Booting User Password Protection
BIOS Integrity Measurement Support
BIOS Protection Support
BIOS Self Recovery
BIOS setup user password
Enhanced Password Strength
HDD User Password Protection and Security
Microsoft Secured-core PC
Microsoft Security Level 3
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
ASUS ExpertGurdian with NIST SP 800 155 compliance
N/A |
| MyASUS feature |
System diagnosis
Battery health charging
Fan Profile
Splendid
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS |
| MyExpert Features |
Advanced Tool
ExpertMeet(All)
SafeGuard Backup(Dual SSD, additional purchase before shipment) |
| Built-in Apps |
ASUS MyExpert (Not supported in China)
AI ExpertMeet (China only)
MyASUS |
| Disclaimer for Built-in Apps |
Built-in Apps vary from OS SKU.
*MyASUS/McAfee don't support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) |
| Reparability Index (for Belgium) |
09.3 |
| Reparability Index (for France) |
09.8 |
| Ecolabels & Compliances |
Energy star 9.0
FSC Recycled |
| Base Warranty |
3Y Pick up/ return |
| Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty |
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgrade
ACX13-007023NX//2Y Extension; 5Y OnSite Service(Next Business Day)*upgrade
ACX14-017300NX//3Y HDD Retention*upgrade
ACX15-011800NX//3Y OnSite Service(Next Business Day); 3Y Accidental Damage Protection*; 3Y HDD_Retention*upgrade
*If you would like to know the details, please contact your sales teams. |
| Battery warranty |
Commercial NB P series Battery warranty follow system warranty. |
| Sustainable Material_Top cover(A part) |
30% PCR recycled plastic(cover or inner frame)
30% PIR recycled aluminum |
| Sustainable Material_Keyboard frame (C part) |
30% PCR recycled plastic(cover or inner frame) |
| Sustainable Material_Bottom cover (D part) |
30% PCR recycled plastic(cover or inner frame) |
| Sustainable Material_Battery |
30% PCR recycled plastic |
| Sustainable Material_Keyboard |
50% PCR recycled plastic cap |
| Sustainable Material_Speaker |
45% PCR + 5% OBP PCR recycled plastic enclosure |
| Sustainable Material_Total PCR recycled plastic |
25% |
