| 43UM5N-H |
| UHD Signage Display |
| |
| |
|
|
| |
| Tech Spec |
| |
| Panel |
| |
- Screen Size: 43"
-
Panel Technology: IPS
-
Back Light Type: Direct
-
Aspect Ratio: 16 : 9
-
Native Resolution: 3,840 × 2,160 (UHD)
-
Refresh Rate: 60 Hz
-
Brightness (Typ.): 500 nit
-
Contrast Ratio: 1,000 : 1
-
Dynamic CR: 1,000,000 : 1
-
Color gamut: BT709 95%
-
Viewing Angle (H x V): 178 × 178
-
Color Depth: 1.07 Billon Colors (10 bit (D))
-
Response Time: Tr : 8ms / Tf :10ms
-
Surface Treatment (Haze): 25 %
-
Life Time (Min.): 50,000 Hrs
-
Operation Hours (Hours / Days): 24 / 7
-
Portrait / Landscape: Yes / Yes
.
|
| |
| |
| Mechanical Specification |
| |
- Bezel Color: Black
-
Bezel Width: 12.1 mm (T/B), 11.1 mm (R/L)
-
Weight (Head): 9.0Kg
-
Packed Weight: 11.3kg
-
Monitor Dimensions (W × H × D): 968 x 559 x 57.7mm (Without IR)
-
Carton Dimensions (W × H × D): 1,055 x 660 x 142mm
-
Handle: No
-
VESA™ Standard Mount Interface: 200 × 200 mm
.
|
| |
| |
| Key Feature |
| |
- Internal Memory 16 GB, Built-in Wi-Fi, Sensor (Temperature Sensor, Auto Brightness Sensor (External IR), Acceleration (Gyro) Sensor), Local Key Operation, Built-in Speaker, webOS 6.0, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Image (Booting Logo Image, No Signal Image), Sync (RS-232C Sync, Local Network Sync), PIP, PBP (4), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Cisco Certi, Crestron Connected®), Smart Energy Saving, PM Mode, Wake on LAN, Network Ready, Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
.
|
| |
| |
| Environment Conditions |
| |
- Operation Temperature: 0 °C to 40 °C
-
Operation Humidity: 10 % to 80 %
.
|
| |
| |
| Power |
| |
- Power Supply: AC 100-240 V ~, 50/60 Hz
-
Power Type: Built-In Power
.
|
| |
| |
| Power Consumption |
| |
- Typ./Max.: 100 W / 140 W
-
Smart Energy Saving (70%): 70W
-
DPM: 0.5W
-
Power off: 0.5W
-
BTU (British Thermal Unit): 341 BTU/Hr(Typ.), 478 BTU/Hr(Max)
.
|
| |
| |
| Certification |
| |
- Safety: CB / NRTL
-
EMC: FCC Class “B" / CE / KC
-
ePEAT (US Only): No
-
ErP / Energy Star: Yes (NewErP) / Yes
-
ISTA6: Yes (~Sep. 23y, US Suffix Only)
-
Carbon Trust: Yes (~Sep. 23y, CO2 Measured)
.
|
| |
| |
| OPS Compatibility |
| |
- OPS Type Compatible: No
-
OPS Power Built In: No
.
|
| |
| |
| Software Compatibility |
| |
- SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG ConnectedCare
.
|
| |
| |
| Connectivity |
| |
- Input: HDMI In (3, 3,840 × 2,160 @ 60Hz, HDCP 2.2/1.4), DP In (3,840 × 2,160 @ 60Hz, HDCP 2.2/1.3), RS-232C In (4 Pin Phone-jack), RJ45 (LAN) In, IR In, USB In 2.0 (Type A)
-
Output: HDMI Out (1, 3,840 × 2,160 @ 30Hz, Input : HDMI1/2/3/DP)
.
|
| |
| |
| Language |
| |
- English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Türkiye, Arabic
.
|
| |
| |
| Accessory |
| |
- Basic: Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender
-
Optional: Slim Wall Mount (WB21LMA/B), Wall Mount (LSW240A/B) Wall Mount Adapter (AM-B220S)
.
|
| |
| |
| Special Feature |
| |
- Tilt (Facedown): Yes (Max 30º degree, 40ºC temperature)
-
IP Rating: IP5X
-
Conformal Coating (Power Board): Yes
.
|
| |
